AC-coupled Outdoor Cabinet Type Energy Storage System

SNE-ESS100A/200A/-30K/50K/100K/150K | 30-150KW | 100-200KWH | Energy Storage System | Lithuim Battery
Designed for small C&I, hospitals, conferences, weak power grid areas

AC-coupled Outdoor Cabinet Type Energy Storage System

SNE-ESS100A/200A/-30K/50K/100K/150K | 30-150KW | 100-200KWH | Energy Storage System | Lithuim Battery
Designed for small C&I, hospitals, conferences, weak power grid areas

AC-coupled Outdoor Cabinet Type Energy Storage System

SNE-ESS100A/200A/-30K/50K/100K/150K | 30-150KW | 100-200KWH | Energy Storage System | Lithuim Battery
Designed for small C&I, hospitals, conferences, weak power grid areas

30kW/50KW/100KW/100KWH-200kWh outdoor cabinet ESS compatible with most moudular LFP battery. Easy to install and dispatch, with built-in HVAC/FSS (optional), and could be used in parallel on AC and/or DC. It is a compact and flexible ESS designed by SUVPR based on the characteristics of small C&I loads. The system integrates core parts such as the battery storage system, PCS, fire extinguishing system, temperature control systems, and EMS systems.

Category:Commercial&Industrial Energy Storage Inverter

battery storage inverter

inverter manufacturers

power inverter

Product Features

Flexible configuration


High integration, small size, easy installation, operation and maintenance
IP54 protection grade, stronger environmental adaptability;

Safe and reliable


Built-in fire extinguishing , temperature control, early warning system multiple security guarantees
Intelligent control system, which can be connected to the local monitoring system for unified management and control;

Intelligent& Friendly


Reducing the maximum demand electricity cost, with considerable economic benefits
Supporting peak shaving and valley filling, and dynamic expansion of transformers;
Benefits
● Integrated design for easy transportation and installation
● Reduce system operating costs
● Can be used for a variety of backup purposes
● Turnkey projects
● Support 7*24 remote service
Benefits
● Power shortage areas
● Off-grid island
● Industrial &commercial energy storage
● Off-grid mine
● C&I user side
● Nomadic farm
Benefits
SNE-ESS100A/200A/-30K/50K/100K/150K | 30-150KW | 100-200KWH | Energy Storage System | Lithuim Battery
Designed for small C&I, hospitals, conferences, weak power grid areas

Application
● Integrated design for easy transportation and installation
● Reduce system operating costs
● Can be used for a variety of backup purposes
● Turnkey projects
● Support 7*24 remote service
Application
● Power shortage areas
● Off-grid island
● Industrial &commercial energy storage
● Off-grid mine
● C&I user side
● Nomadic farm
Application
SNE-ESS100A/200A/-30K/50K/100K/150K | 30-150KW | 100-200KWH | Energy Storage System | Lithuim Battery
Designed for small C&I, hospitals, conferences, weak power grid areas
Model SNE-ESS100A/200A-30K/50K/100K/150K
DC data
Battery capacity (kWh) 100KWH~200KWH
Number of battery racks 1~2
BMS communication interface RS485/CAN
DC voltage range(V) 420V~850V
AC data
Rated AC power(kW) 30KW~150KW
Max. AC power(kW) 30KW-150KW
Rated AC current(A) 43A~216A
Max. AC current(A) 48A~238A
DC current component <0.5%
THDi <3% (Rated power)
Rated grid voltage(V) 400V
Allowable grid voltage range(V) 320~460
Rated grid frequency(Hz) 50/60Hz
Allowable grid frequency range(Hz) 45-55/55-65Hz
Power factor 1lagging-1leading
Isolation method With the isolation
General Data
Ingress protection IP54
Fire extinguishing system Support
Operating temperature -30~+55℃
Dimension W*D*H (mm) Customization*1,300*2,400
Weight (kg) Customization
BMS communication mode CAN, RS485
EMS communication mode RS485, TCP/IP
PCS cooling way Temperature control intelligent air cooling
Battery cooling way Air conditioning cooling
Altitude 4,500m (>3,000 Derating)
