High Voltage Residential LiFePO4 Energy Storage Battery-BYD Cell

Grade A BYD cell | 10.24KWH | 15.36KWH | 20.48KWH | High Voltage Battery | Support ODM/OEM service

High Voltage Residential LiFePO4 Energy Storage Battery-BYD Cell

Grade A BYD cell | 10.24KWH | 15.36KWH | 20.48KWH | High Voltage Battery | Support ODM/OEM service

High Voltage Residential LiFePO4 Energy Storage Battery-BYD Cell

Grade A BYD cell | 10.24KWH | 15.36KWH | 20.48KWH | High Voltage Battery | Support ODM/OEM service

The 10.24-20.48KWH high voltage LiFePO4 battery is a high-tech product developed to meet the requirements of new solar battery storage system. It has the characteristics of modular, lightweight, intelligent, easy to install, portable. And all internal structures have been remotely certified and confirmed by BYD. It uses the BYD vehicle grade (LFP) battery to meet residential energy storage demands, the modular design can meet your current and future solar energy storage needs.

Category:Residential Energy Storage Systems

solar panel battery storage

solar power energy storage

lithium battery

Product Features

Flexible configuration


High-voltage LiFePO4 battery module
single module is 51.2V 50Ah
Stackable design and easy installation

Safe and reliable


BYD vehicle grade (LFP) battery:
More Safety, Longer life Cycle
More Usable Energy life up to 10 years;
Applicable for residential and commercial system applications;
Flexible Scalable from 10 to 20 KWH;
Optimization of high-powered emergency-backup and off-grid function;

Abundant configuration


Matching with leading inverter brands
Compatible with CAN / RS485 communication interface
Applicable on grid or hybrid on
and off-grid solar energy storage system
Benefits
● BYD original blade battery cell
● BYD original battery PACK module
● BYD original BMS/BMU/BCMU
● BYD original structure design
● BYD original technical solutions
● BYD original sales record
Benefits
● Villa
● Household
● Farm
● Base Station
● Field Power Supply
Benefits
Grade A BYD cell | 10.24KWH | 15.36KWH | 20.48KWH | High Voltage Battery | Support ODM/OEM service

























































Application
● BYD original blade battery cell
● BYD original battery PACK module
● BYD original BMS/BMU/BCMU
● BYD original structure design
● BYD original technical solutions
● BYD original sales record
Application
● Villa
● Household
● Farm
● Base Station
● Field Power Supply
Application
Grade A BYD cell | 10.24KWH | 15.36KWH | 20.48KWH | High Voltage Battery | Support ODM/OEM service



Model SNE1024LFP SNE1536LFP SNE2048LFP
Performance
Battery type Lithium-iron phosphate (LiFePO4)
Nominal Battery Energy(KWH) 10.24KWH 15.36KWH 20. 48KWH
Nominal Capacity 50AH 50AH 50AH
 Nominal Voltage(V) 204.8V  307.2V  409.6V
Operating Voltage Range(V) 172.8V~224.64V  259.2V~345.6V  345.6V~460.8V
 Number of battery Modules 4 6 8
 MAX. constant charging current(A) 50A(@25°C)
Recommend charge current(A) 10~25A
Max.constant discharging current(A) 50A(@25°C)
Depth of discharge(DOD) 80%
Cell technology BYD Lithium-iron phosphate (LiFeP04)
Design life 5000times @80%DOD
Warranty 5 years
Warranty Document Supplied Yes
Compatible hybrid inverters SNE8K-G3/SNE10K-G3/SNE12K-G3 or other hybrid inverters
Protection function
Protection Over-temperature, over charge, under-voltage, over-current, short circuit alarm Function
Display and Communication
Display The information of Battery, such as SOC, battery voltage and so on
Communication CAN/RS485
General Specification
 Dimension (L*W*H)(MM) 600*210*1140MM 600*210*1300MM  600*210*1620MM
Weight(KG) 155.5KG 182KG 235KG
Operating Temperature -20°C-+55°C
Max. operating altitude 4,000m(Derating above 2,000m)
Protection degree IP21,indoor installation
Relative humidity 5%-95%
Cooling Natural convection
 Noise emission <29 db
Certification TUV/CE/IEC/UN38.3/UL1973.. ..
